Safety lock is placed on edge of exit tube, inside oil separator, and it´s purpose is to prevent leaking of separated light oils in natural recipient. It is made of float who is moving together with separation line between water and light fluids. When level of light fluids is increased, float is falling and getting near to pipe opening.In moment when level of light fluid is increased so much that it threats to get out in recipient, float get in to pipe opening and prevent its leaking from separator.
Securing Devices
SHAFT FOR SAMPLE COLLECTING
Before release waste water in to the recipient, it is necessary to take sample of purified water for testing in authorized laboratories. Samle must satisfy certain criteria (guaranteed outlet parameters), guaranteed by the manufacturer of the device.
ACCESSORIES FOR EXTRACTION OF SLUDGE OR OIL FROM SEPARATOR
Tools are made in way that enables simple sludge extraction (oil) from separators. On cover of oil separator are placed corresponding coupling on which device for sludge or oil extracting is pluging in.
SAMPLING PUMP
In a case of bigger depth of shaft for sampling, we are able to offer special pump for collecting samples. Investor is, thus, much easier to performe quality control process of wastewater that is discharged into the recipient.
OIL SKIMMER
Oil skimmer is device which is for oil, fat or other carbonhidrates, separation from water surface. The device is equipped with a hose, belt or disc that passes by water surface and binds fats or oils for it own surface. Collected oil or fat is removed using a scraper and then drained in to the tank. For extraction of more complexed fat on the device is set of heaters to soften the fat and facilitate its removal. Oil skimmers are used for extracting oil from the coolant, oil separators, grease separators, in the treatment of industrial waste water in the wells and the places where it is necessary to extract the floating oil and grease from liquids
